| Pitch range | 4 mm – 10 mm |
| Brightness | 5000 – 8000 cd/m² |
| Viewing angle | 120° H × 120° V |
| Protection (front/rear) | IP65 / IP43 |
| Operating temp | -20°C ~ +50°C |
| Lifespan | 100.000 saat |
| Technology | SMD / DIP |
| Module size | 32 × 16 cm |
| Cabinet size | 96 × 96 cm |
Outdoor LED screens are used on building façades, roadside billboards, mall and hotel entrances, city squares and car park entrances — anywhere content must be readable from a distance and in daylight. Unlike a printed sign, content can be changed remotely in seconds, so one screen does the work of several static ad faces.
Start with pixel pitch: as a rule of thumb, the P value in metres is the comfortable viewing distance. Street-level façades suit P4–P5; billboards viewed from 20 m or more suit P8–P10. Next is brightness: direct sunlight needs 5000–8000 cd/m², and our screens dim automatically at night. IP65 front / IP43 rear protection keeps them running from -20°C to +50°C.
Finally, plan installation and maintenance access: flush façade mounts use front-serviceable modules, while steel-structure billboards keep a rear service path. Structural and wind-load calculations are part of the site survey.
Mayled is a manufacturer, not an importer: every cabinet is built, tested and shipped from our facility in Yenimahalle, Ankara. Site survey, structural and electrical planning, installation, commissioning and after-sales service are handled by one team, so responsibility never gets split.
Spare modules and parts are kept in stock. If a module fails it is swapped from the front or rear in minutes without taking the whole screen down. Pick your size in the configurator for an instant estimate, or book a site survey with our team.
No. IP65 protection makes them dust- and water-tight, operating reliably through rain, snow and temperature swings.
Yes. 5000-8000 cd/m² brightness ensures clear visibility even in direct sunlight.
Rule of thumb: pitch (mm) ≈ minimum viewing distance (m). P10 for 10m+, P6 for 6m+, P4 for closer viewing.
100,000 hours — over 22 years at 12 hours/day operation.
Configure your project in 3 minutes — our team will follow up.
